The range of SmartPipe™ pipe-to-pipe and stud connectors provides versatility of design and helps to overcome constraints often encountered with the structure of industrial buildings.
- Quick connections
- Full bore design
- Interchangeable and reusable
- Non-flammable materials (UL 94-HB standard)
- Maximum working pressure: 232 psi
- Vacuum: 98.7% (29.6" Hg)
- Normal working temperature: -4°F to 140°F
Unit of Measure
Specifications
Series |
N/A 6605 |
Weight |
N/A 47.62 oz |
C |
N/A 2 1/2 inches |
E |
N/A 25.0 |
Normal Working Pressure |
N/A 188 psi |
Thread Code |
N/A 41 |
Body Material |
N/A Treated Brass |
G |
N/A 91.0 |
Suitable Fluids |
N/A Compressed Air Inert Gases Vacuum |
Excellent Resistance |
N/A Compressor Oils (mineral or synthetic) Ultra-violet Rays |
Maximum Working Pressure |
N/A 232 psi |
Vacuum |
N/A 98.7 % (29.6" Hg) |
Normal Working Temperature |
N/A -4 to 140 ºF |
Storage Temperature |
N/A -40 to 176 ºF |
Ø D |
N/A 63 |
H |
N/A 130.5 |
Nut Material |
N/A Treated Aluminum |
