  • Ultra compact design and wide range of flow rates, make it the perfect generator for a variety of lower flow nitrogen applications.
  • Significant cost savings over cylinder or liquid supply provides a typical return on investment of less than 24 months.
  • Uses pressure swing adsorption to produce a continuous, uninterrupted supply of 95 to 99.999% purity nitrogen gas from clean, dry compressed air.
  • 100% functional tested with 2 year warranty.
  • Eliminates safety concerns associated with transporting and storing pressurized gas cylinders or liquid nitrogen.
  • Reduces carbon footprint by eliminating gas delivery with positive impacts on sustainability targets.
Unit of Measure

Financing

Approve Payments

 N/A Finance with Approve Payments

Specifications

Brands

 N/A nano

Maximum Oxygen Content for 99.999 Percent (%) Nitrogen Purity

 N/A 10 ppm

Rated Outlet Flow at 99.999 Percent (%) Nitrogen Purity

 N/A 64 scfh

Maximum Oxygen Content for 99.995 Percent (%) Nitrogen Purity

 N/A 50 ppm

Rated Outlet Flow at 99.995 Percent (%) Nitrogen Purity

 N/A 106 scfh

Maximum Oxygen Content for 99.99 Percent (%) Nitrogen Purity

 N/A 100 ppm

Rated Outlet Flow at 99.99 Percent (%) Nitrogen Purity

 N/A 120 scfh

Maximum Oxygen Content for 99.95 Percent (%) Nitrogen Purity

 N/A 500 ppm

Rated Outlet Flow at 99.95 Percent (%) Nitrogen Purity

 N/A 166 scfh

Maximum Oxygen Content for 99.9 Percent (%) Nitrogen Purity

 N/A 0.10 %

Rated Outlet Flow at 99.9 Percent (%) Nitrogen Purity

 N/A 194 scfh

Maximum Oxygen Content for 99.5 Percent (%) Nitrogen Purity

 N/A 0.50 %

Rated Outlet Flow at 99.5 Percent (%) Nitrogen Purity

 N/A 279 scfh

Maximum Oxygen Content for 99 Percent (%) Nitrogen Purity

 N/A 1 %

Rated Outlet Flow at 99 Percent (%) Nitrogen Purity

 N/A 350 scfh

Maximum Oxygen Content for 98 Percent (%) Nitrogen Purity

 N/A 2 %

Rated Outlet Flow at 98 Percent (%) Nitrogen Purity

 N/A 431 scfh

Maximum Oxygen Content for 97 Percent (%) Nitrogen Purity

 N/A 3 %

Rated Outlet Flow at 97 Percent (%) Nitrogen Purity

 N/A 498 scfh

Maximum Oxygen Content for 95 Percent (%) Nitrogen Purity

 N/A 5 %

Rated Outlet Flow at 95 Percent (%) Nitrogen Purity

 N/A 664 scfh

Note for Rated Outlet Flow

 N/A At 101.5 psig and 77ºF inlet conditions. Contact nano for flow, pressure and purity outside listed range.

Dimension A

 N/A 73 in

Dimension B

 N/A 17 in

Dimension C

 N/A 18 in

Approximate Weight

 N/A 249 lb

Recommended Inlet Air Quality (International Organization for Standardization (ISO) Class)

 N/A 2.2.1

Minimum Inlet Air Quality (International Organization for Standardization (ISO) Class)

 N/A 2.4.1

Minimum Operating Pressure

 N/A 87 psig

Maximum Operating Pressure

 N/A 145 psig

Recommended Operating Temperature Range

 N/A 68 to 77 ºF

Minimum Operating Temperature Range

 N/A 41 ºF

Maximum Operating Temperature Range

 N/A 122 ºF

Alternating Current (AC) Supply Voltage

 N/A 100 to 240 V

Fuse Rating

 N/A 3A 'T'

Frequency

 N/A 50 to 60 Hz

Maximum Power Consumption

 N/A 72 W

Ingress Protection (IP) Rating

 N/A Ingress Protection Rating (IP53) (National Electrical Manufacturers Association (NEMA) 2)

Pressure Correction Factors

Pressure Correction Factors at 87.0 Pounds per Square Inch Gauge (psig) Inlet Pressure

 N/A 0.88

Pressure Correction Factors at 101.5 Pounds per Square Inch Gauge (psig) Inlet Pressure

 N/A 1.00

Pressure Correction Factors at 116.0 Pounds per Square Inch Gauge (psig) Inlet Pressure

 N/A 1.10

Pressure Correction Factors at 130.5 Pounds per Square Inch Gauge (psig) Inlet Pressure

 N/A 1.20

Pressure Correction Factors at 145.0 Pounds Per Square Inch Gauge (psig) Inlet Pressure

 N/A 1.30

Temperature Correction Factors

Temperature Correction Factors at 41 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.80

Temperature Correction Factors at 50 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.90

Temperature Correction Factors at 59 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.94

Temperature Correction Factors at 68 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 1.00

Temperature Correction Factors at 77 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 1.00

Temperature Correction Factors at 86 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.98

Temperature Correction Factors at 95 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.95

Temperature Correction Factors at 104 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.90

Temperature Correction Factors at 113 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.85

Temperature Correction Factors at 122 Degree Fahrenheit (ºF) Inlet Temperature

 N/A 0.72

Features

N/A

  • Eco-mode energy savings control reduces energy consumption during periods of low demand.
  • Optional integrated O2 analyzer and dew point sensors (N2 or inlet air).

Note for Pressure and Temperature Correction Factors

N/A To be used as rough guide only. All applications should be confirmed by nano.
