Republic offers a complete line of centrifugal blowers for vacuum or compressed air applications. Centrifugal blowers provide dry, clean, oil-free air and require low energy consumption. Unlike compressed air systems, this series is safe to run at low pressure, and allows for increased production speeds or levels.

The RB800 is robust and hard-working. The blower comes with ceramic hybrid bearings, rotatable outlet discharge, easy to remove stainless steel bearing housing assembly, and zinc plated steel motor pulley.
Unit of Measure

Financing

Approve Payments

 N/A Finance with Approve Payments

Specifications

Model

 N/A RB800

Frequency

 N/A 50 Hz60 Hz

Power

 N/A 10 hp

Motor Frame Size

 N/A 215TC

Maximum Flow at 50 Hertz (Hz) Frequency

 N/A 950 ft³/min1614 m³/h

Maximum Flow at 60 Hertz (Hz) Frequency

 N/A 975 ft³/min1657 m³/h

Maximum Vacuum at 50 Hertz (Hz) Frequency

 N/A 69 in. H2O172 mbar

Maximum Vacuum at 60 Hertz (Hz) Frequency

 N/A 75 in. H2O189 mbar

Maximum Pressure at 50 Hertz (Hz) Frequency

 N/A 84 in. H2O209 mbar

Maximum Pressure at 60 Hertz (Hz) Frequency

 N/A 99 in. H2O247 mbar

Sound Level with Enclosure

 N/A 82 dB

Sound Level without Enclosure

 N/A 96 dB

Weight

 N/A 226 lb102 kg

Retro Kit Weight

 N/A 69 lb32 kg

Warranty

 N/A 1 year

Dimensions

Dimension A

 N/A 20.5 in517 mm

Dimension B

 N/A 8.00 in229 mm

Dimension C

 N/A 7.00 in178 mm

Dimension D

 N/A 23.00 in587 mm

Dimension E

 N/A 8.50 in216 mm

Dimension F

 N/A 12.00 in332 mm

Dimension G

 N/A 0.75 in19 mm

Dimension H

 N/A 8.00 in210 mm

Dimension I

 N/A 12.00 in308 mm

Dimension J

 N/A 8.00 in206 mm

Dimension K

 N/A 4.00 in101 mm

Dimension L

 N/A 0 3.98 in0 92 mm

Dimension M

 N/A 10.25 in260 mm

Dimension N

 N/A 4.00 in114 mm

Dimension O

 N/A 6.50 in165 mm

Dimension P

 N/A 3.00 in76 mm

Dimension Q

 N/A 10.00 in254 mm

Available Options

N/A Republic Centrifugal Blowers are made to order, and can be customized to fit almost any application. Many common options and accessories are listed below. For additional options, please contact Republic or your local distributor.

Options

N/A Hard anodized bearing housing assembly Inlet and outlet flanges Water-cooled blower

Accessories

N/A Enclosures for noise control Exhaust silencer Starter panel Variable frequency drive
