Republic RTAF Tube Axial Fans provide flow capacities up to 27,000 cfm in diameters ranging from 12" to 36". These powerful, direct drive fans feature welded and powder-coated steel bodies, spark-resistant impellers, and TEFC motors with a single point electrical connection. These industrial fans are maintenance free, designed for continuous operation, and ideal for a variety of applications including ventilation, heat removal, process air movement, and in-line duct boosters.
Unit of Measure

Financing

Approve Payments

 N/A Finance with Approve Payments

Specifications

Model

 N/A RTAF-30

Maximum Flow Rate

 N/A 18,250 ft³/min

Maximum Pressure

 N/A 4.00 in. H2O

Fan Diameter

 N/A 30 in

Motor Speed

 N/A 1800 rpm

Power

 N/A 7.5 hp

Voltage

 N/A 230 V460 V

Current

 N/A 9.5 A19.0 A

Weight

 N/A 241 lb

Dimension A

 N/A 26.49 in673 mm

Dimension B

 N/A 35.40 in899 mm

Dimension C

 N/A 31.76 in807 mm

Advantages

N/A

  • Capacities up to 27,000 cfm
  • Pressures up to 4.75"H2O
  • Eight standard diameters - 12" - 36"
  • Direct driven TEFC motors (washdown available)
  • Powder-coated steel body
  • Spark-resistant impeller
  • Precision balanced prior to assembly
  • Fan guard is standard
  • Integral rolled flanges
